Heavy Hitter Surron V2 Skid Plate

A redesigned 7075-T6 billet aluminum skid plate built to fit all motors, with re-optimized bash plate angles for enduro riding and tighter controller fitment to protect phase wires from sticks and rocks. At 3.42 lbs with a 10mm bash plate tested to withstand over 6,000 lbs of impact force, it's the most robust skid plate available for this platform. Adds rigidity to the frame while protecting the motor.

Fitment:

• Sur Ron LBX / S

• Segway X160 / X260


Download Tech Sheet (Assembly & Torque Specs)

Lifetime Warranty on Side Rails — if they ever bend, we replace them for free. (Not applicable to bash plates; replacements available upon request.)

The bash plate angles are thoroughly tested to eliminate drag and momentum loss when sliding over obstacles. Aluminum skids over rocks and logs easier than plastic since sharp surfaces can't embed into it. Strategic ventilation slats keep the motor cool, the extended tail section protects from perpendicular strikes, and each section is easily removable for routine maintenance. The replaceable bash plate swaps out in minutes. If you are looking for the lightest Skid Plate for your bike check out our Heavy Hitter Nomad!

Guides

Download Tech Sheet (Assembly & Torque Specs)

Installation Note: Use blue medium thread locker on all hardware. Mounting bolts are T20 Torx; recommended torque value is 2.6 Nm / 1.92 ft-lb / 23 in-lb. Barely hand-tight with thread locker applied correctly will hold securely and remain removable.
